Ritchie DNB-200 Navigator Compass – Binnacle Mount – Black [DNB-200]

Navigator Compass

Features:

• 4 1/2 (115 mm) PowerDamp Open Face Dial with Large Numerals
• Ideal for both Power and Sailboats
• Fits all Popular Sailboat Steering Pedestals
• Easily Installed
• Stainless Housing selections: Brushed stainless, powder-coated black, or powder-coated white
• 12v Green LED lighting Standard
• Built-in Compensators to Easily Adjust for Deviation
• Movable Sun Shield
• 45 Degree Lubber Lines
• High Temperature Construction for Extended Operating Range
• Weather Shield available. Model No.WS-P
• 100% Repairable
• Exclusive 5-Year Ritchie Warranty

Approx. Shipping Weight:3lbs 10oz (1.65 kg)

Notes:

12v lighting standard – 24 & 32v lighting options are available.

Specifications:

• Mounting Style: Binnacle
• Lubber Lines: Yes
• Read: Rear
• Backlight: Yes
• Box Dimensions: 7″H x 8″W x 8″L WT: 3.6 lbs
• UPC: 010342150219

Quick Guide (pdf)
Owner’s Manual (pdf)
