Ritchie F-83 Voyager Compass – Flush Mount – Black [F-83]

Voyager Compass

Features:

• 3 (76 mm) CombiDamp Dial
• Easily Installed
• Exclusive Built-in Green NiteVu Night Illumination
• Built-in Compensators to Easily Adjust for Deviation
• Scientifically Matched Sapphire Jewel and Hardened Steel Pivot Dial Movement
• Powerful DirectiveForce Magnets for Fast Heading Lock-on
• Movable Sun Shield
• High Temperature Composite Construction for Extended Operating Range
• 100% Repairable
• Exclusive 5-Year Ritchie Warranty

Approx. Shipping Weight: 1lb 8oz (680g)

Notes:

All magnetic compasses come standard with 12v lighting. 24 & 32v lighting options are available.

Uses 2 sets of lights.

Specifications:

• Read: Both
• Mounting Style: Flush
• Lubber Lines: Yes
• Backlight: Yes
• Box Dimensions: 5″H x 8″W x 9″L WT: 1.2 lbs
• UPC: 010342141002

Quick Guide (pdf)
Owner’s Manual (pdf)
