Ritchie HB-741 Helmsman Compass – Bracket Mount – Black [HB-741]

Helmsman Combidial Compass

Features:

• 3 3/4 (95 mm) Open Face Dial or CombiDial
• Adjustable and Removable with Bracket and Thumbscrews
• Exclusive Built-in Green NiteVu Night Illumination
• Built-in Compensators to Easily Adjust for Deviation
• Scientifically Matched Sapphire Jewel and Hardened Steel Pivot Dial Movement
• Powerful DirectiveForce Magnets for Fast Heading Lock-on
• Movable Sun Shield
• 45 Degree Lubber lines
• High Temperature Composite Construction for Extended Operating Range
• 100% Repairable
• Exclusive 5-Year Ritchie Warranty

Approx. Shipping Weight: 2lbs (907g)

Notes:

Comes standard with 12V lighting. 24 & 32V lighting options are available. Some custom built OEM models may have different lighting.

Specifications:

• Read: Both
• Mounting Style: Bracket
• Lubber Lines: Yes
• Backlight: Yes
• Box Dimensions: 7″H x 8″W x 8″L WT: 2.45 lbs
• UPC: 010342138613

Quick Guide (pdf)
Owner’s Manual (pdf)
