Ritchie S-53G Explorer Compass – Surface Mount – Gray [S-53G]

Explorer Compass

Features:

• 2 3/4 (70 mm) Easy to Read Direct Reading Dial
• Compact Low-Profile Design
• Quick Push-Button Removal of Compass Module for Storage and Security
• Choice of Colors
• Internal Green Night Illumination
• Built-in Compensators to Easily Adjust for Deviation
• Scientifically Matched Sapphire Jewel & Hardened Steel Pivot Dial Movement
• Powerful DirectiveForce Magnets for Fast Heading Lock-on
• Movable Sun Shield
• High Temperature Composite Construction for Extended Operating Range
• 100% Repairable
• Exclusive 5-Year Ritchie Warranty

Approx. Shipping Weight: 1lb (454g)

Notes:

All compasses come standard with 12v lighting. 24v lighting option is available. Some custom built OEM models may have different lighting.

Specifications:

• Read: Front
• Mounting Style: Surface
• Backlight: Yes
• Lubber Lines: Yes
• Box Dimensions: 4″H x 5″W x 5″L WT: 0.8 lbs
• UPC: 010342160454

Quick Guide (pdf)
Owner’s Manual (pdf)
