Ritchie V-57.2 Explorer Compass – Dash Mount – Black [V-57.2]

Explorer Compass

Features:

• 2 3/4(70 mm) Direct Reading Dial
• Easily Installed, Fits 3 Instrument Hole.
• Bezels Styled to Match Popular Gauge Packages
• 12v Night Illumination
• Viewing is adjustable to 30 degrees
• Choice of Traditional Black or Designer White Colors
• Scientifically Matched Sapphire Jewel & Hardened Steel Pivot Dial Movement
• Built-in Compensators to Easily Adjust for Deviation
• Hi-Temperature Construction
• 100% Repairable
• Exclusive 5-Year Warranty

Approx. Shipping Weight: 1lb (454g)

Notes:

All compasses come standard with 12v lighting. 24v lighting option is available. Some custom built OEM models may have different lighting.

Specifications:

• Read: Front
• Mounting Style: Dash
• Backlight: Yes
• Lubber Lines: Yes
• Box Dimensions: 5″H x 6″W x 6″L WT: 0.8 lbs
• UPC: 010342160614

Quick Guide (pdf)
Owner’s Manual (pdf)
